V3 Oval LED Parking Garage Light | 30W/40W/60W Selectable | 3CCT Tunable | Motion Sensor Ready | Up to 9,000 Lumens | DLC Premium
SKU:
UTLED-1064
- $73.79
$81.17- $73.79
- Unit price
- per
Free shipping on orders over $99
We promise same day shipping
Get your quote within 1 hour!
The UpgradeToLED V3 Oval LED Parking Garage Light is a versatile commercial lighting solution designed specifically for parking garages, underground parking structures, hallways, stairwells, and covered outdoor areas. Featuring field-selectable wattages of 30W, 40W, and 60W along with selectable 3000K, 4000K, and 5000K color temperatures, this fixture provides maximum flexibility for contractors, facility managers, and retrofit projects.
Powered by premium Lumileds 2835 LED chips, the fixture delivers up to 9,000 lumens with an industry-leading efficacy of 150 lumens per watt, providing bright, uniform illumination while significantly reducing energy consumption and maintenance costs compared to traditional HID fixtures.
The unique oval housing design combined with a wide 154.3° beam angle ensures exceptional light distribution throughout parking garages, hallways, and underground facilities, minimizing dark spots and improving safety and visibility. The high-quality anti-UV polycarbonate optic lens delivers consistent light output while maintaining long-term durability.
Constructed from rugged die-cast aluminum housing with a corrosion-resistant white powder-coated finish, the fixture is designed to withstand demanding commercial environments. The fixture is IP65-rated for wet-location protection and features optional plug-and-play occupancy sensor compatibility for additional energy savings.
For enhanced emergency preparedness, the fixture supports an optional 18W emergency battery backup driver, providing illumination during power outages. Standard 0-10V dimming compatibility allows integration with modern lighting control systems and building automation platforms.
Designed for operation on 120-277VAC, the V3 Oval Parking Garage Light can be installed using surface-mount junction box installation, side-entry wiring, or pendant mounting via a 3/4-inch threaded conduit connection.
Ideal for parking garages, underground parking structures, apartment complexes, commercial buildings, hallways, walkways, warehouses, and covered parking facilities requiring reliable, energy-efficient illumination.
Key Features
- Wattage Selectable:
- 30W
- 40W
- 60W
- 3CCT Selectable:
- 3000K
- 4000K
- 5000K
- Up to 9,000 lumens
- Industry-leading 150 LM/W efficacy
- Premium Lumileds 2835 LED chips
- Wide 154.3° beam angle
- Unique oval fixture design
- Motion sensor compatible
- Optional occupancy sensor
- Optional 18W emergency battery backup
- 0-10V dimmable
- Anti-UV polycarbonate optics
- Die-cast aluminum housing
- White powder-coated finish
- IP65 wet-location rated
- ETL Listed
- DLC Premium Listed
- 50,000-hour rated lifespan
Technical Specifications
| Specification | Details |
|---|---|
| Brand | UpgradeToLED |
| Product Type | Oval LED Parking Garage Light |
| Model | LS-3NCP30/40/60W-XXK |
| Wattage Selectable | 30W / 40W / 60W |
| Lumen Output | 4,500 / 6,000 / 9,000 Lumens |
| Light Efficiency | 150 LM/W |
| Color Temperature | 3000K / 4000K / 5000K |
| CRI | >72 |
| Input Voltage | 120-277VAC |
| Power Factor | >0.90 |
| Input Current | 0.25A / 0.33A / 0.50A @120V |
| LED Chips | Lumileds 2835 |
| Driver | UL Listed KHM Dimmable |
| Beam Angle | 154.3° |
| Housing Material | Die-Cast Aluminum |
| Finish | White Powder-Coated |
| Lens Material | High-Quality Oval PC Optics |
| Dimming | 0-10V |
| Motion Sensor | Optional |
| Emergency Backup | Optional 18W Driver |
| Operating Temperature | -20°C to 45°C |
| Junction Temperature | <75°C |
| Fixture Efficiency | ≥90% |
| Mounting Options | Surface Mount / Side Wiring / 3/4" Pendant Mount |
| Dimensions | 12.2" × 12.2" × 5.1" |
| Lifetime | 50,000 Hours |
| Certifications | ETL Listed, DLC Premium |
| Equivalent HID Replacement | 100W-250W HPS/MH |
| Warranty | 5-Year Limited |
Applications
- Parking Garages
- Underground Parking Structures
- Apartment Complexes
- Hallways
- Stairwells
- Commercial Buildings
- Covered Walkways
- Parking Decks
- Warehouses
- Retail Facilities
- Security Lighting
- Utility Areas
